  • Ting Chou Metal Wire Co., Ltd. - logo

  • Ting Chou Metal Wire Co., Ltd.

  • Interconnects Connectors Power connectors

Description

SPECIFICATIONS:

  • INSULATOR: Nylon-66, UL94V-0
  • CONTACT: Brass.
  • PLATING: Full Tin.
  • CURRENT RATING: 5A.
  • WITHSTANDING VOLTAGE: 1500V AC.
  • INSULATION RESISTANCE (MIN.): 1000MΩ.
  • CONTACT RESISTANCE (MAX.): 20mΩ.
  • OPERATING TEMPERATURE: -25℃ ~ +85℃.

Supplier Information

Ting Chou Metal Wire Co., Ltd.

TEL : 886-2-2673-9458 FAX : 886-2-2671-5587
No 15, Lane 318, Jie Shou Road, Sec. 1, New Taipei City, Taiwan - Roc
Web-Site : http://www.tingchou.com.tw/
E-Mail : michelle@tingchou.com.tw
