- Interconnects Plugs, Jacks & Sockets IC sockets
-
-
12703S1TXXXX4XX
Straight Type
Description
SPECIFICATIONS:
- INSULATOR: Polyester, UL94V-0
Standard: PPS - CONTACT: Phosphor Bronze.
- PLATING: Full Tin / 120μ”
- CURRENT RATING: 1A.
- WITHSTANDING VOLTAGE: 500V AC.
- INSULATION RESISTANCE (MIN.): 1000MΩ.
- CONTACT RESISTANCE (MAX.): 30mΩ.
- OPERATING TEMPERATURE: -40℃ ~ +105℃.
